PERFECT INDUSTRIAL PACKAGING

Pallet collars are a modern and efficient replacement for traditional wooden boxes and crates.Especially suitable for precious, fragile goods. Pallet collars have excellent loading capacity, the dynamic load can reach 2 tons, the static load can reach 6 tons to 8 tons.

STANDARDIZED PRODUCT

Standardized dimensions have a large impact on the standard warehousing, efficient transportation and use cost of the goods. Our standard size: British(in): 40 "×48". Metric(mm) 600×800，800×1200, 1000×1200. It can also be customized

EASY TO USE

Fast assembly by one person, height arbitrary selection, save time and labor, operate safety

EFFICIENT TRANSPORTATION

Save up to 80% of storage and transportation space when not in use.

WAREHOUSING OPTIMIZATION

Flexible stacking with accessories to save storage space

HIGHLY DURABLE

Reusable, returnable, repairable, working life up to 10 years

PALLET COLLAR LUMBER

Grade	specification (thickness × length)	Standard
A+	20mm×195mm	four-sided planning no holes no cracks,
A-	20mm×195mm	four-sided planning with holes and cracks
B+	18/19mm×195mm	three-sided planning no holes no cracks
B-	18/19mm×195mm	three-sided planning with holes and cracks

HINGES

Item	specification (thickness×length)	material	surface treatment
Hinges.	1.2mm×218mm	Steel	Hot dip galvanizing treatment

RIVENT

Item	specification (thickness×length)	material	surface treatment
Solid rivet	5mm×25mm	Steel	Hot dip galvanizing treatment
Hollow rivet	5mm×25mm	Steel	Hot dip galvanizing treatment

Item	specification (thickness×length)	material	surface treatment
Pin	4mm×180mm	Steel	No

DISTANCER

Item	specification (thickness×length)	material	surface treatment
Distancer	171mm×428mm	Steel	Hot dip galvanizing
Distancer	171mm×428mm	Steel	Baking paint

Reinforced Corners

Effectively reduce the risk of crates shifting/falling when they are moved or stacked upon one another

Item	Length×width×height	material
corner	95mm×95mm×80mm	polyethylene
